ISUZU MU-X (07/2021 ONWARDS) - TOUGH DOG 40MM ADJUSTABLE FRONT LIFT - PREASSEMBLED STRUTS

Isuzu MU-X (07/2021 onwards) - Tough Dog 40mm Adjustable Front Lift - Preassembled Struts

Tough Dog

Type: MU-X

Year: 07/2021 onwards

Suspension Type: Coil Spring Front

Front Lift: 40mm

Detail: 40mm Bore Adjustable Shock
Front Preassembled Struts & Coils


The kit contains:

  • 2x Tough Dog 40mm Adjustable - Front Preassembled Strut & Coils
Customise your kit below:
* Front Load Options
Upgrade Cost: 0
$1,156.00
Tax included
Quantity
 Calculate Shipping Cost

Type: MU-X

Year: 07/2021 onwards

Suspension Type: Coil Spring Front

Front Lift: 40mm

Detail: 40mm Bore Adjustable Shock
Front Preassembled Struts & Coils


40mm Bore Adjustable Shock Absorbers

The 40mm adjustable shock brings the ability to fine tune your ride control to just about every 4WD user. The shock offers 9 different stages of adjustment, to fine tune the ride characteristics to your personal preference and application.

Features:

  • 40mm internal bore
  • 60mm external casing
  • 18mm chrome-plated rod
  • High temperature, all weather oil
  • Foam cell
  • 9 Stage external adjustment
  • Additional welding on all studs and eye rings
  • 4 Year / unlimited km Recreational warranty (Conditions Apply)
  • 3 Year / unlimited km Commercial warranty (Conditions Apply)

Important Notes for setting up your Vehicle Correctly:

  • When selecting Springs to suit your lift, please Select Springs only to suit Current "CONSTANT" Loads Front and Rear.
  • Towing Loads are not included in your Constant Load Calculations, as they are not "Constant" Loads.
  • Please do not put Occasional Loads into your "Constant" Load determinations.
  • Selecting a load rating that is too heavy for your setup will result in Poor Flex Off-Road, Compromised Suspension Travel & Rough Ride, and will cause damage to your new shock absorbers and other components by pushing them outside of their intended range.

Please Note:

  • All lift heights stated are estimated lift heights, due to the large number of variables in each different vehicles setup and accessories.

Data sheet

Make
Isuzu
Model
MU-X
Series
UCS40 - Mid 2021 on
Brand
Tough Dog
Shock Type
Tough Dog 40mm Adjustable
Type
Front Lift
Lift Height
40-50mm
